Za procesorje 12. in 13. generacije



Intel Core i7-13700

Intel Core i7-13700F

Intel Core i5-13500

Intel Core i5-13400

Intel Core i5-13400F

Intel Core i3-13100

Intel Core i3-13100F



Intel Core i7-12700

Intel Core i7-12700F

Intel Core i5-12600

Intel Core i5-12500

Intel Core i5-12400

Intel Core i5-12400F

Intel Core i3-12300

Intel Core i3-12100

Intel Core i3-12100F



Overall Height	Up to 47mm (top of fan to bottom of heatsink)
Overall Size	Up to 100mm x 100mm
Mass	Up to 350g
Sound Power Level	3.9 BA (2400 RPM, 40C inlet, 65W); 4.6 BA (max RPM)
Sound Pressure Level	29 dBA (2400 RPM, 40C inlet, 65W)
TDP Support	Up to 65W (12th Gen Intel® Core™ Desktop Processors)
Fan Type	PWM controlled variable speed fan
Connector Type	4-pin
Operating Voltage	13.2V max, 12.0V rated, 10.8V min
Current (peak)	Up to 400mA
Max RPM (+/- 5%)	Up to 3150 RPM
Min RPM (+/- 20%)	600 RPM
Operating Temp	0 to 70C
Operating Humidity	85% relative humidity @ 55C
Fan Protection	Locked-rotor/polarity protected
Sense Frequency	2 pulses/Rev, 12V pull-up with 10Kohm
PWM Frequency	25KHz +/- 5KHz
PWM Pull-up Voltage	5.25V max
PWM Duty Cycle Range	0–100%
