Shipping (inner) case net weight
15.6 kg
Master (outer) cases per pallet (air)
24 pc(s)
Pallet gross length
110 cm
Shipping (inner) case height
39.3 cm
Pallet gross weight (sea)
682.9 kg
Products per pallet (air)
72 pc(s)
Products per pallet (sea)
120 pc(s)
Products per shipping (inner) case
3 pc(s)
Pallet gross weight (air)
419.7 kg
Shipping (inner) case length
53.9 cm
Master (outer) cases per pallet (sea)
40 pc(s)
Pallet height (air)
131.4 cm
Pallet height (sea)
2.1 m
Shipping (inner) case width
29.5 cm
Pallet gross width
120 cm
Shipping (inner) case gross weight
16.4 kg
Form factor
1U
LED indicators
Activity
,
Power
,
Link
,
Fan fail
,
Speed
Product colour
Grey
,
Black
Safety
CCC, CE LVD, UL/cUL
Rack mounting
Yes
Number of fans
2 fan(s)
Electromagnetic compatibility
FCC A, CE A, VCCI, C-Tick, BSMI, CCC
AC input frequency
50 - 60 Hz
Power consumption (typical)
27.49 W
AC input voltage
100 - 240 V
Access Control List (ACL)
Yes
Authentication
Guest VLAN, MAC-based authentication, Port-based authentication
Security algorithms
802.1x RADIUS
,
SNMP
,
SSH
Loop protection
Yes
Access Control List (ACL) rules
256
SSH/SSL support
Yes
IP-MAC-Port binding
Yes
DHCP features
DHCP client
IGMP snooping
Yes
BPDU filtering/protection
Yes
Operating temperature (T-T)
-5 - 50 °C
Operating relative humidity (H-H)
10 - 90%
Heat dissipation
850.58 BTU/h
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Traffic classification
Yes
Web-based management
Yes
Switch layer
L2
Quality of Service (QoS) support
Yes
Switch type
Managed
System event log
Yes
Width
440 mm
Depth
210 mm
Height
44 mm
Networking standards
IEEE 802.3
,
IEEE 802.3ab
,
IEEE 802.1p
,
IEEE 802.1Q
,
IEEE 802.3x
,
IEEE 802.3ad
,
IEEE 802.1s
,
IEEE 802.1w
,
IEEE 802.1x
,
IEEE 802.3az
,
IEEE 802.1v
,
IEEE 802.1D
,
IEEE 802.3z
,
IEEE 802.3ah
,
IEEE 802.3u
Rate limiting
Yes
VLAN support
Yes
Auto-negotiation
Yes
Virtual LAN features
Tagged VLAN
,
Port-based VLAN
,
Voice VLAN
,
MAC address-based VLAN
Copper ethernet cabling technology
10BASE-T
,
100BASE-T
,
100BASE-TX
,
1000BASE-T
IP routing
Yes
10G support
No
Port mirroring
Yes
Number of VLANs
4094
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Spanning tree protocol
Yes
Auto MDI/MDI-X
Yes
Mean time between failures (MTBF)
294101 h
Built-in processor
Yes
Memory type
DDR3-SDRAM
Noise level
52.4 dB
Flash memory
32 MB
Internal memory
128 MB
Package height
92 mm
Package width
365 mm
Package depth
521 mm
Package weight
5.18 kg
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Fiber optic connector
SFP
Console port
RJ-45
Basic switching RJ-45 Ethernet ports quantity
24
SFP module slots quantity
4
Harmonized System (HS) code
85176990
Switching capacity
56 Gbit/s
MAC address table
16000 entries
Number of static routes
32
Store-and-forward
Yes
Number of queues
8
Forwarding rate
41.7 Mpps
Jumbo frames support
Yes
Packet buffer memory
1.5 MB
Jumbo frames
9216
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
24
Multicast support
Yes
Multicast Listener Discovery (MLD) snooping
MLD v1, MLD v2
Fiber ethernet cabling technology
1000BASE-X
